Charging Tough Sleeve - USB Cig Plug Charger
With Quick Release Integrated Charging Dock
Charging Tough Sleeve with Quick Release Integrated Charging Dock. Designed for heavy-duty environments the tough sleeve encloses the device without the need to remove it to charge. Simply dock the device onto the Quick Release Charging Dock and the charging terminals will provide the charging connection. The Sleeve can be easily removed by pressing the release lever.
The AMPS pattern mounting holes make it easy for quick attachment to any flat surface or mounting brackets such as our Heavy Duty Pedestal or Forklift Mounts.
- Fits Apple iPad Air (A1474, A1475, A1476)
- Control buttons are accessible when the device is in the sleeve.
- 12/24 input USB A Cig Plug Charger.
- Made of high-grade ABS and Acetal plastic. Colour Black
- Made in Sweden.
- 12 Months Warranty.
Please Note: Mounting of this Tough Sleeve onto a ClicOn Dashmount is not advisable.
Charging specifications
- Input voltage: DC/10-30V
- Charging voltage: DC/4.75-5.3V
- Output current(Typ): 2.0A
- Input & output protection: Input polarity reversal/Output over voltage/Output over current/Output short protection
- LED charging indicator: Power input indicator(Green), Ovp/Ocp/Output short(Red)
- Operating temperature: 0°C ~ +40°C
- Storage temperature: -20°C ~ +80°C
- RoHS compliant: ROHS
This Holder Fits | Apple iPad Air (A1474, A1475, A1476) |
SKU | 558920 |
Barcode # | 7320285589209 |
Brand | ClicOn |
Below you will find the installation instructions for the Charging Tough Sleeve - USB Cig Plug Charger (SKU:558920), you can click on the images to open a larger version in a new tab
Step 1
1. To place the device in the sleeve: Place the device onto the back part of the sleeve. Carefully connect the charging connector to the device. NOTE: It is essential to hold the connector straight in front of the device and connect it straight to the device (if you angle the connector/place it askew into the device, you risk damaging the connector/device). Place the front part/frame over the device and attach it by screwing the enclosed screws into place on the back side of the sleeve. The device is now securely in place and can not be removed without loosening the screws.
Step 2
2. To install the active MultiMoveClip: Loosen the screw in the centre of the Power Block so you can remove the tilt swivel attaching plate on the back. Place the attaching plate in the desired position and screw it into place with the enclosed screws. Place the Power Block over the attaching plate, so the screw fits in the hole in the tilt swivel. Tighten the screw until the MultiMoveClip is firmly in place but still can be adjusted.
Step 3
3. To place the sleeve onto the active MultiMoveClip: Place the sleeve above the Power Block and slide/press it straight downward into the Power Block, so you hear/feel it snaps into place. The device is now connected to the charging. To remove the sleeve from the active MultiMoveClip: Press forward on the release arm on the Power Block, so the sleeve is set free. Press/lift the sleeve straight upward, out from the Power Block.
